AB-330M
Portable
Portable thermal printer 80mm. Bluetooth, USB and serie. 60mm/s. Lithium battery. Includes storage bag.
BASIC INFORMATION |
|
| Type | Direct portable thermal printer |
| Part Number (P/N) | POS2137 |
| Model | AB-330M |
| Resolution | 203DPI (8dots/mm) |
| Printing speed | Max 60mm/seg |
| Interfaces | Bluetooth, USB, Serie |
| Compatibility | Windows / Linux / Android |
| Dimensions | 100 x121 x 46 (LxWxH) |
| Data sheet |
N/D |
SPECIFICATIONS |
|
| Printing Mode | Direct thermal printing |
| Printing speed | Max 60mm/seg |
| Printing Length | 72mm |
| Cutting type | Manual |
| Resolution | 576 dots/line (8 dots/mm) |
| Buffer | 4Kb |
| Interfaces | Bluetooth, USB, Serie |
| Sensors | Paper end error |
| Compatibility | Windows / Linux / Android |
| Emulations | ESC / POS |
| Other functions |
Energy saving mode Sleeping mode |
Printing fonts |
|
| Characters per line | Font A:48CPL,FontB:64CPL |
| Characters size | Font A:12×24,FontB:9×17 |
Barcode |
1D:CODE39,CODE93,CODE128,EAN-8,EAN-13 |
PAPER |
|
| Paper type | Thermal paper |
| Size | 79mm +/- 0.5mm |
| Paper thickness | 0.06 até 0.08mm |
| Roll diameter | Máx. 40mm |
| Printing length | 72mm |
| Paper supply methode | Drop-in |
| Cutting mechanism | Manual |
Reliability |
|
| Print head lifetime | 50Km |
| MCBF | 100.000.000 lines |
Other |
|
| Dimensions | 100 x121 x 46 (LxWxH) |
| Weight | 275g |
| Operating temperature | Standby: -20ºC~60ºC | Running: 0ºC~50ºC |
| Humidity | 10~90% |
| Battery | Rechargable lithium battery 7.4V / 1.5Ah |
| Battery cycle | Rechargable up to 500 times |
| Charging time | 1100mAh: Aprox 75 min | 2200 mAh: Aprox. 116 min |
| DC 9V/2A | |
| Certification | CE | FCC | MIC | ROHS |
